Leigh Router Table Dovetail Jig Accessory Kit

Get the most out of your new Leigh Jigs Router Table Dovetail Jig with this accessory kit. This fully loaded expansion kit includes a wide range of dovetail bits in various pitch angles and sizes to let you make pins and tails in any style you like. The kit also includes a straight bit and two spiral bits for varying sizes of box joints (finger joints), as well as a collet reducer and the e-Bush e7 guide bushing.

Important Router Table Requirements

Router tables are not commonly used with guide bushings because either a bearing or fence is used. The Leigh eBush system is designed around the decades-old Porter Cable/Black & Decker industry standard. If you do not already have tha router table plate that accepts the Porter Cable-style guide bushings, then you will need to adapt your current model or purchase a plate that accepts these bushings.

Features Include:

• (4) 8° - 8mm shank Dovetail bits for through dovetails
  • 1/4", 5/16" x 3/8", 7/16"
• (2) 1/2" - 1/2" shank Dovtail bits for half-blind dovetails
  • 12° & 18° pitch angles
• (1) 5/16" - 8mm shank Straight Bit for through dovetails
• (1) 3/16" HSS sprial upcut bit for box joints
• (1) 3/32" - 1/4" shank HSS straight bit,
• (1) e-Bush (e7) for half pitch through dovetails
• (1) 1/2" to 8mm Collet Reducer

Uses in your shop:

• Safely make perfect dovtails, box joints (finger joints), and half-blind dovetails on your router table
